A stationary mast–type material hoists is a device for lifting construction materials, equipment, and tools. It consists of one or two masts – strong metal trusses, an electric motor, a lifting system, and a working platform with sides on which loads are placed.
With the help of the material hoists, you can lift construction materials, tools, and equipment. A material hoist can have one or two masts – strong metal trusses.
The device is also equipped with an electric motor, a working platform on which the loads are located, as well as a lifting system. The trolley is moved along the support using steel ropes. The features of the material hoists allow you to install them outside or indoors.
Advantages of Stros material hoists:
Large load capacity up to 2 tons;
The lifting height can vary from 19 to 350 meters;
Lifting speed reaches 25 meters per minute;
The mounting system is simple;
Multiple levels of security;
Management does not require special knowledge and skills;
The background noise does not exceed the permissible level.
Platform Hoist
Max. height: | 19 m |
---|---|
Max. weight: | 200 kg |
Speed: | 25 m/min |
Platform Hoist
Max. height: | 60 m |
---|---|
Max. weight: | 200 kg |
Speed: | 25 m/min |
Characteristics | ALULIFT 200 S | ALULIFT 200 V | NV 2038 F4 |
Delivery height | max. 19 m to cornice | max. 60 m | 350 m |
Load capacity | 200 kg | 200 kg | 2000 kg |
Lifting speed | 25 m/min | 25 m/min | 40 m/min |
Masts | — | — | S |
Internal dimensions of the lift | — | — | 1390 x 3800 mm |
Supply system | 1 NPE 50 Hz 230V | 1 NPE 50 Hz 230V | — |
Drive motor power | 1,5kW | 1,5kW | 2 x 9,2kW / 2 x 12HP |
Informations | — | — | operated from base station, only for material transport |
Control voltage | 24В AC | 24В AC | — |
Rated current [400V / 480V] | — | — | 68A / 57A |
Starting current [400V / 480V] | — | — | 102A / 85,5A |
Main protection [400V / 480V] | — | — | 90A / 80A |
Recommended fuse protection [400V / 480V] | — | — | 100A / 100A |
Stros material hoists can be used in the construction of various buildings, repair of roofs, facades, and installation of engineering networks. Our company is the official distributor of Stros in Nigeria. We supply only proven equipment and provide a quality guarantee.
The manufacturer Stros offers various models of devices, namely:
lightweight models. They have mechanisms made of aluminum, and can lift loads up to 200 kilograms to a height of up to sixty meters;
heavy-weight models. With their help, you can lift loads up to two tons to a height of up to 350 meters.
The units can be equipped with one or two electric motors.
The advantages of Stros material hoists can be distinguished:
cost-effectiveness. If your finances do not allow you to purchase the presented equipment, you can rent it. Thanks to simple installation and quick commissioning, you can save time and material resources;
versatility. With the help of material hoists, you can move any loads.
security. Material hoists are equipped with catchers, limit switches, etc.
You can order material hoists on our website or by phone. We provide individual and favorable conditions for each client.
