Hoist NOV 1832 UP
Hoist NOV 1832 UP
Hoist NOV 1832 UP
Main parameters
  • Internal dimensions of the cabin:
    1990 x 3100 x 2400 mm 6'6 3/8'' x 10'2 1/16'' x 7'10 1/2''
  • Load capacity:
    1800 kg / 3970 lbs
  • Maximum lifting speed:
    35 m/min / 115 fpm
  • Engine power:
    2 x 11 kW / 2 x 15 hp
12 months warranty
Lift rental
Low noise level (about 65dB)
Can be installed inside and outside the building
From design to installation
All parameters
Internal dimensions of the cabin: 1990 x 3100 x 2400 mm 6'6 3/8'' x 10'2 1/16'' x 7'10 1/2''
Standard door height 2000 mm / 6'6 3/4"
Load capacity: 1800 kg / 3970 lbs
Maximum lifting speed: 35 m/min / 115 fpm
Engine power: 2 x 11 kW / 2 x 15 hp
Frequency converter -
Rated current [400 V / 480 V] 55A/ 50A
Starting current [400 V / 480 V] 275A / 250A
Starting current [400 V / 480 V] 63 / D
Recommended fuse connection [400 V / 480 V] 70A / 70A
Counterweight -
Masts BH, S, (H in the shaft)
Maximum lifting height 350 m / 1150 ft
Possibility of installing two cabins per 1 mast yes
Control system Joystick / Button / Keyboard

Lift NOV 1832 UP

Spare parts catalog is available upon request
